Panasonic AG-UX180 4K Premium Professional Camcorder

Panasonic AG-UX180 4K Premium Professional Camcorder. Panasonic introduces the 4K camcorder UX series to meet professional 4K video production needs. The AG-UX180 is the premium model with professional functions and specifications for high-end users.
This model is equipped with a newly designed compact lens featuring a wide 24mm angle and 20x optical zoom as well as a 1.0-type (effective size) high-sensitivity MOS sensor. Its evolved Optical Image Stabilizer (O.I.S.) and intelligent AF function suitable for professional camera work.
The AG-UX180 supports 4K 24p, UHD 60p/50p, FHD 60p/50p multi-format recording and HD super slow-motion.

Just for you

Two SD memory card slots*4 are provided to enable relay/simultaneous/ backup recording for enhanced reliability, and also support UHD/FHD*5 dual codec recording for a more efficient workflow. The controls of the AG-UX180, such as the manual three rings and user button, as well as interfaces, such as 3G-SDI/HDMI and XLR input, are engineered to meet the needs of professional video recording. Offering the same level of agility and mobility as the conventional HD handheld camcorder, the AG-UX180 provides powerful support for high-image-quality 4K video production.

Key Specifications

Panasonic AG-UX180 4K Premium Professional Camcorder

The AG-UX180 is the premium model in the 4K UX Professional Camcorder Series, featuring a 1” (effective size) high-sensitivity MOS sensor and the industry’s widest angle zoom lens (20x to 24mm at the widest angle). With its extensive focus assist features, multiple recording formats in 4K and HD, as well as precise image adjustment functions, the highly-affordable UX180 is the pro camcorder you’ve been waiting for to upgrade to 4K acquisition.

High Performance 4K LEICA Dicomar Lens

The AG-UX180 is one of the world’s first 1” sensor cameras (with an integrated lens) to feature 20x optical zoom. Combined with the industries widest lens (24 mm), it ensures you get the shot you need, near or far, with the ability to take your frame from 24 mm (wide) to 480 mm (telescopic) in no more than 2 seconds. The i.Zoom function (HD mode only) increases the zooming capability to a maximum of approximately 30x zoom, while still maintaining high resolution. If needed, Digital Zoom (2x, 5x or 10x) gives you super-telephoto magnification equivalent to a 300x zoom without a significant drop in light intensity.

4K Optical Image Stabilization

Using a handheld camera, encountering shooting conditions, such as low-angle, high-angle or zoomed in shots, which result in visible handshake is inevitable. The UX180 is equipped with an advanced O.I.S. system which uses the measure of small balls inside the camera to correct the stability of your image. This, paired with a 5-Axis (Roll / Pitch / Yaw / X / Y) Hybrid Image Stabilizer helps detect and correct unwanted handshake.

Easier Focusing in 4K

Using a handheld camera, encountering shooting conditions, such as low-angle, high-angle or zoomed in shots, which result in visible handshake is inevitable. The UX180 is equipped with an advanced O.I.S. system which uses the measure of small balls inside the camera to correct the stability of your image. This, paired with a 5-Axis (Roll / Pitch / Yaw / X / Y) Hybrid Image Stabilizer helps detect and correct unwanted handshake.

Variety of Recording Formats

The variety of recording modes with selectable image quality, frame rate and bit rate settings are ideal for a wide range of applications, from cinema production to online distribution. Images can be recorded with a resolution of 4K (4096 x 2160)/24p, UHD (3840 x 2160)/60p or FHD (1980 x 1080)/60p. Versatile and easy-to-use MOV (QuickTime), MP4 and AVCHD file formats are supported.

IR (Infrared) Shooting in Dark Places

The IR Cut Filter can be turned ON/OFF (allocated on the User button). When the filter is turned OFF, IR lights (sold separately) can be used for shooting in dark places.

Variable Frame Rates

VFR (2 fps to 60 fps)
FHD VFR (variable frame rate) Recording: VFR recording can be set in 10 steps from 2 fps to 60 fps (60Hz) / 9 steps from 2 fps to 50 fps (50Hz).

Slow Motion

Super-Slow Motion (120 fps/100 fps)
Super-Slow Motion: Slow-motion effect can be achieved by highspeed HD recording at 120 fps (59.94 Hz) or 100 fps (50 Hz).

Dual SD Memory Card Slots

The AG-UX180 comes equipped with two SD cards slots, enabling options such as unlimited relay recording, simultaneous recording, background recording and UHD/FHD Dual Codec recording. Dual codec recording allows for simultaneous capture of UHD 30p and FHD, or FHD and FHD low bit rates, which essentially produces master and offline/proxy versions of footage. An efficient workflow can be achieved by using the Sub Rec File for tasks such as previews, offline editing and Internet data transfers.

Precise Image Adjustments

The UX180 comes fully equipped to help provide you with the best possible colored image, featuring broadcast-grade camera image adjustments, such as 16-axis color correction. Easily match the look of any other camera you may be shooting with, and create your own scene files.

Versatile Professional Interfaces

Equipped with the features you would expect from a camera far more expensive than this one, the UX180 comes with a 3G-SDI output for connecting to an external 1080/60p recorder, a TC preset in/out terminal for time synch/synchronized multi-camera recording, two channels of XLR audio input for professional high-quality audio recording and HDMI output for on-shoot 4K video monitoring.
